Designed specifically for dual power line AC systems, this two-line emi power line filter targets engineers and system integrators requiring stable electromagnetic compatibility solutions. Its compact form factor and through-hole package enable straightforward integration into varied control boards or enclosures. This product addresses the need for mitigating conducted electromagnetic interference on mains supply lines rated at 250 VAC and 1 A, ensuring compliance requirements are met in diverse electrical installations. It delivers consistent noise suppression while maintaining system integrity, serving as a reliable component for users demanding interference reduction in their power networks.
The emi power line filter features a stopband attenuation range between 70 and 100 dB, effectively minimizing radio-frequency interference within its 6 MHz passband. Operating at 50/60 Hz frequency, it incorporates a self-resetting zero noise overvoltage protection circuit designed to prevent metal-oxide varistor (MOV) aging, thereby extending operational lifespan. Its insertion loss exceeds 100 dB at 50 ohm input impedance, reinforcing low idle power consumption and reliability under normal operating voltage and current, rated at 250 VAC and 1 A respectively. Certification compliance, including UL, VDE, CSA, CE, CQC, and ROHS, substantiates its suitability for regulated environments and international standard conformance.
| RATED VOLTAGE | 250 VAC | ||
| RATED CURRENT | 1A | ||
| LINES NUMBER | 2 | ||
| FREQUENCY | 50/60Hz | ||
| PASS BAND | 6M | ||
Within industrial control panels, multiple sensitive electronic devices coexist, necessitating stringent electromagnetic interference control for operational stability. The emi power line filter manufacturer supplies filters tailored for dual-line power inputs, effectively suppressing conducted EMI that could degrade programmable logic controllers, sensors, and motor drives. By attenuating noise in the mains power feeds, the filter contributes to overall EMC conformity, preventing equipment malfunction and facilitating compliance with IEC and EN standards. Its compact footprint and standardized mounting enable seamless integration within panel enclosures, optimizing spatial arrangements without compromising EMI mitigation performance.
In laboratory settings and RF shielding rooms, power line disturbances can critically affect test accuracy and equipment reliability. The emi power line filter addresses this challenge by ensuring that supplied AC mains remain free from conducted electromagnetic noise, which is essential for sensitive instrumentation calibration and validation. Its high stopband attenuation and self-resetting protection circuitry safeguard measurement integrity and prevent damage from transient voltage events. As a component, it integrates directly into shielded enclosure power feeds, supporting regulatory requirements and enabling high-precision testing workflows by maintaining a stable, interference-limited environment critical for research and development activities.
We are a leading professional EMI filter manufacturer with over 10 years of expertise in designing effective and cost-efficient solutions. Our technical team is skilled in adhering to international safety standards such as UL, VDE, CSA, CE, CQC, and military applications.
Our EMI power line filter products hold multiple certifications including UL, VDE, CSA, CE, CQC, and RoHS. These certifications ensure that our filters meet stringent safety and environmental standards required for industrial and commercial applications worldwide.
Yes, we provide customization services for clients seeking tailored solutions. Our experienced technical team can adapt filter parameters such as rated current, voltage, and package type to fit your unique application and compliance demands.
Our filter uses a through-hole package design, allowing straightforward mounting into standard enclosures or control boards. The dual-line input/output setup simplifies wiring for AC power supply lines, making installation efficient in both new and retrofit projects.
We ship globally via EMS, DHL, FedEx, UPS, or TNT, and provide online tracking numbers so you can monitor your shipment status directly. We handle logistics efficiently to ensure timely delivery of your EMI power line filter orders to your facility.
Yes! We fully support sample testing and provide free EMC rectification technical support and conduction tests for new clients.
