380VAC 300A emi filter for power supply
· General purpose,three phase four line Power Filter
· Excellent interference suppression performance for CM and DM
· High quality components,high performance/cost
· Chassis mounting with various connection:fast on/bolt/wire terminals
· Made to order acceptable
Typical Application
· General Purpose Three Phase Four Line Filtering
· High power office equipment
· Installations comprising automation equipment
· Mainframe computer systems and further three-phase + neutral electricity supply
· UPS
Specification:
| Product Name | Three Phase EMI Filter |
| Model | PE3300-8-06 |
| Rated Voltage | 250/440/480VAC |
| Rated Current | 5A~1200A |
| Operating Frequency | 50/60Hz |
| Temperature range | HPF 25/085/21 |
| Test Voltage(1 min) | Line to Ground :1450VAC |
|
Line to Line :2700VDC |
Description
|
General purpose,three phase three line filters,space-saving design |
|
Rated current from 5A to 200A |
|
Excellent interference suppression performance for CM and DM |
|
High quality components ensure the safety and reliability of filter |
|
Chassis mounting with various connection: fast on/screw/wire terminal |
|
Custom design acceptable |
Typical Application
|
General purpose three phase filtering |
|
Three-phase motor drives |
|
Inverters and converters |
|
UPS and SMPS |
|
Industrial automation equipment |
