Optimized Solution for Shielded Enclosure EMI Control
This 50ohm 380VAC 150-200A Emi Power Line Filter is designed to meet the demanding needs of industrial and military-grade shielded enclosures. The product targets engineers and technical buyers requiring high-current capacity filters that suppress electromagnetic interference effectively. Its compatibility with shielded environments ensures integration with complex electrical systems where power integrity and EMI compliance are critical. This rf filters supplier solution addresses interference in power lines, making it essential for applications involving sensitive electronics and high-current power distribution networks.
Technical Specifications Enabling Superior EMI Suppression
Engineered with a nominal voltage rating of 380VAC and a rated current support of 100A (with 140% overload capacity), this filter delivers performance under strict electrical standards. Its insertion loss exceeds 100dB from 14kHz to 40GHz, ensuring extensive EMI mitigation. A minimal voltage drop below 1V and harmonic distortion under 2% optimize power transmission efficiency. The 1000VDC dielectric withstand voltage between line-to-line and line-to-case enhances electrical safety. As an rf filter product, it adheres to military and international test standards, guaranteeing robust mechanical and electrical properties suited for critical EMI control.
Applicable Industries and Contributions to Reliable Operations
Ideal for deployment in power distribution systems and shielded electronic enclosures, this filter supports compliance with safety certifications including UL, VDE, CSA, CE, and CQC. Its effectiveness in reducing conducted interference and harmonic distortion contributes to improved operational stability and reduced downtime in industrial electronics, military platforms, and testing laboratories. By partnering with an experienced rf filters manufacturer, businesses benefit from technical support and filter durability that maintain system integrity while aligning with regulatory requirements and product lifecycle demands.
Product Advantages
Structural Design and Integration Efficiency
The power line filter features a compact yet robust design tailored for shielded enclosures, delivering consistent performance under environmental and electrical stress. Its 50ohm input impedance and adherence to MIL-STD-202, MIL-F-15733, and MIL-STD-220A ensure structural reliability and thermal stability. This design enables seamless integration within existing shielded systems, facilitating modular installation and maintenance. By providing a stable interface between power sources and load equipment, this product from a reputable rf filters supplier minimizes electromagnetic leakage and mechanical failures.
Enhanced Performance and Operational Reliability
The filter’s low voltage drop and leakage current parameters contribute to efficient power delivery and reduced energy losses, critical for high-current industrial applications. Its high insertion loss guarantees noise suppression across a wide frequency band, addressing both conducted and radiated EMI concerns. This reliability extends filter life expectancy and reduces maintenance requirements. Clients gain operational value through minimized interference risk, improved system certification compliance, and accessible technical support for troubleshooting, reflecting the strengths of the rf filter’s performance profile.
Product Description
|
RATED VOLTAGE
|
380 VAC
|
|
RATED CURRENT
|
100 A
|
|
Voltage Drop
|
Less than 1V
|
|
Overload
|
140% of rated current for 15 minutes
|
|
Harmonic Distortion
|
Less than 2% @ full rated current
|
|
Leakage Current
|
≤0.2A@380/230VAC and 50Hz
|
|
Dielectric Withstanding Voltage
|
1000VDC (line to line) 1000VDC (line to case)
|
|
DC Insulation Resistance
|
As Per MIL-STD-202 Method 202
|
|
Terminal Strength
|
As Per MIL-STD-202 Method 211
|
|
Temperature Rise
|
As Per MIL-F-15733
|
|
Insertion Loss
|
≥100dB@14K-40GHz As Per MIL-STD-220A, Under Load Condition
|
|
Climatic Classification
|
25/070/21
|
We are a professional and famous EMI filter manufacturer.
Our technical team has more than 10 years’ experience in designing EMI filter. We know UL VDE CSA CE CQC etc safety standard very well.
Our technical service team learn many kinds of test standard such as industrial application (IEC61800-3 for frequency inverter drive EN12015 for elevator EN55011 for ISM device etc) and military application (GJB151A GJB152A etc).We can solve EMI problem quickly effectively and low-costly.
