Carbon Polyurethane Rf Absorbing Foam Liner

Name: Carbon Polyurethane Rf Absorbing Foam Liner rf shielded room and emc anechoic chamber
Brand: changzhou hezi international trading co.,ltd.
Availability: InStock
Rating: 5 (1 reviews)

Carbon Polyurethane Rf Absorbing Foam Liner rf shielded room and emc anechoic chamber

High Light

Polyurethane RF Absorber Foam, Carbon RF Absorber Foam, rf absorbing foam liner

Size

600*600 Or Customized

Height

10 30 50 80 100

Color

Blue

Reflectivity

10-50dB

Customized

Port

Shanghai

Place of Origin

Jiangsu, China

Brand Name

Haozhuo

Certification

CE RoHS

Model Number

HZ series

Minimum Order Quantity

>=1 Square Meters

Price

$50.00

Packaging Details

carton

Supply Ability

1000000 Square Meter/Square Meters per Week

Description

Soaked carbon polyurethane foam for EMC Chambers

EPP foam absorber is based on expandable polyprolyene matrix and designed by ohmic dissipation of carbon black (CB). CB is electric carbon material with nano size and high specific surface area. In our technology, EPP is the wave-transparent matrix and CB material is absorbing agent. By combination of these two, a kind of light, water-proof, moisture-proof, acid-base resistance, ageing resistant and size stable microwave absorber is produced.

RF Foam Absorber Types

· Rubber sheet micromave absorber

· Carbon-based foam microwave absorber

· Honeycomb & high power microwave absorber

· Sprayable microwave absorber

· Rigid and castable microwave absorber

TYPE	BASE SIZE	NUMBER OF PYRAMIDAL	WEIGHT	TOTAL HEIGHT	BASE HEIGHT	PYRAMIDAL HEIGHT	PYRAMIDAL WIDTH
HZ-30	500*500	36*36	1.1	30	15	15	14
HZ-50	500*500	20*20	1.8	50	20	30	25
HZ-70	500*500	20*20	2.5	70	20	50	25
HZ-100	500*500	13*13	3.3	100	25	75	38
HZ-150	500*500	9*9	4.8	150	30	120	56
HZ-200	500*500	7*7	6.3	200	40	160	71
HZ-300	500*500	5*5	9	300	60	240	100
HZ-400	500*500	4*4	12	400	70	330	125
HZ-500	500*500	3*3	15	500	80	420	167
HZ-600	400*400	2*2	18	600	90	510	200
HZ-700	250*500	1*2	21	700	100	600	250
HZ-800	250*500	1*2	24	800	100	700	250
HZ-1000	334*334	1*1	30	1000	150	850	3

TYPE	HEIGHT	REFLECTIVITY
TYPE	HEIGHT	40	15	10	3	1.5	0.5	0.3	0.2	0.15
HZ-100	100	50	45	40	30	20
HZ-150	150	50	50	45	33	25
HZ-200	200	50	50	50	37	30	17
HZ-300	300	50	50	50	40	33	20
HZ-400	400	50	50	50	45	40	25	17
HZ-500	500	50	50	50	45	40	30	20	17
HZ-600	600	50	50	50	50	40	30	25	20
HZ-700	700	50	50	50	50	43	35	30	20	17
HZ-800	800	50	50	50	50	45	36	30	20	17
HZ-1000	1000	50	50	50	50	45	38	35	25	20

RF Foam Absorber Basic Information

· Base size: 500*500mm, customized acceptable

· Standard height: 30,50,100,150,200,300,400,500,700,800,1000mm

RF Foam Absorber Features

· The traditional material for anechoic chambers

· Outstanding absorbing over a wide frequency range

· Flexible
