Electromagnetic interference (EMI) filters are crucial for a wide range of equipment and devices. Installing an EMI filter helps them function as intended and prevent them from interfering with other devices. Electromagnetic compatibility (EMC) is also a key component of meeting the compliance requirements of global regulations and many industry standards. For EMI filters to provide desired performance, they must be installed correctly. Following best practices for installing EMI filters helps in optimizing their performance and ensures safe compliance margins for the devices.
|
RATED VOLTAGE
|
250 VAC
|
||
|
RATED CURRENT
|
30 A
|
||
|
OPERATIONAL FREQUENCY
|
50 60 Hz
|
||
|
Voltage Drop
|
Less than 1V
|
||
|
Overload
|
140% of rated current for 15 minutes
|
||
|
Harmonic Distortion
|
Less than 2% @ full rated current
|
||
|
Leakage Current
|
≤0.2A@380/230VAC and 50Hz
|
||
|
Dielectric Withstanding Voltage
|
1000VDC (line to line) 1000VDC (line to case)
|
||
|
DC Insulation Resistance
|
As Per MIL-STD-202 Method 202
|
||
|
Terminal Strength
|
As Per MIL-STD-202 Method 211
|
||
|
Temperature Rise
|
As Per MIL-F-15733
|
||
|
Insertion Loss
|
≥100dB@14K-40GHz As Per MIL-STD-220A, Under Load Condition
|
||
|
Climatic Classification
|
25/070/21
|
||
Grounding Tips
Grounding also called earthing, is a crucial part of a system and EMI filter installation where problems often occur. To avoid these issues, keep these EMI filter installation guidelines in mind.
It's important to remember that there is a difference between an EMI/system ground and a safety ground. Safety ground is a connection or a conductor providing a path for currents to flow during a circuit fault. Interference currents occur at high frequencies, which means that typical safety ground isn’t adequate for EMI. The high impedance of these systems can result in increased radiated emissions from the system and its sensitivity to interference from external sources. For EMI, a grounding system is needed that has very low impedance for the high frequency (HF) signals.
Key ground design objectives for EMC
Minimizes Crosstalk
Minimizes Emissions
Minimizes Susceptibility
We are a leading EMI filter manufacturer with over 10 years of expertise in designing effective and cost-efficient solutions. Our technical team is skilled in adhering to international safety standards such as UL, CE, CSA, and military applications. We provide high-quality and reliable products to customers worldwide, ensuring they meet the highest performance standards.
Why Choose Us:
1.Who are we?
We are a global leader in the design and manufacturing of EMI filters, offering customized solutions for a wide range of industries.
2.How can we guarantee quality?
We ensure quality through extensive testing with advanced equipment and strict compliance with international safety and performance standards.
3.What can you buy from us?
You can purchase EMI filters, RF shields, Faraday cages, and other EMC-related products.
4.Why should you buy from us instead of other suppliers?
We stand out for our unparalleled product quality, competitive pricing, excellent customer service, and a 2-year warranty on all products.
5.What services can we provide?
We offer custom product design, comprehensive EMI testing, and ongoing technical support for all our products.
